Nominal Diameter
鋼絲繩公稱直徑

Approx.Weight
鋼絲繩近似重量

Nominal Tensile Strength of Rope 鋼絲繩公稱抗拉強度(MPa)

1470

1570

1670

1770

1870

D


Allowed
Tolerance
允許偏差

NF
天然纖維
芯鋼絲繩

SF
合成纖維
芯鋼絲繩

Minimum Breaking Load of Rope 鋼絲繩最小破斷拉力


mm

kg/100m

KN

8
9
10
11
12
13
14
16
18
20
22
24
26
28
30
32
34
36
38
40
42
44
46
48
50
52
54
56
58
60
62
64
66
68
70
72
74
76
78
80

±6%
















20.40
25.80
31.80
38.50
45.80
53.70
62.30
81.40
103.00
127.00
154.00
183.00
215.00
249.00
286.00
326.00
368.00
412.00
459.00
509.00
561.00
616.00
673.00
733.00
795.00
860.00
927.00
997.00
1070.00
1140.00
1220.00
1300.00
1390.00
1470.00
1560.00
1650.00
1740.00
1840.00
1930.00
2040.00

19.50
24.60
30.40
36.80
43.80
51.40
59.60
77.80
98.50
122.00
147.00
175.00
206.00
238.00
274.00
311.00
351.00
394.00
439.00
486.00
536.00
589.00
643.00
700.00
760.00
822.00
886.00
953.00
1020.00
1090.00
1170.00
1250.00
1320.00
1410.00
1490.00
1580.00
1660.00
1760.00
1850.00
1950.00

26.30
33.30
41.20
49.80
59.30
69.60
80.70
105.00
133.00
165.00
799.00
237.00
278.00
323.00
370.00
421.00
476.00
533.00
594.00
659.00
726.00
797.00
871.00
948.00
1030.00
1110.00
1200.00
1290.00
1380.00
1480.00
1580.00
1690.00
1790.00
1900.00
2020.00
2130.00
2250.00
2380.00
2500.00
2630.00

28.10
35.60
44.00
53.20
63.30
74.30
86.20
113.00
142.00
176.00
213.00
253.00
297.00
345.00
396.00
450.00
508.00
570.00
635.00
703.00
775.00
851.00
930.00
1010.00
1100.00
1190.00
1280.00
1380.00
1480.00
1580.00
1690.00
1800.00
1910.00
2030.00
2150.00
2280.00
2470.00
2540.00
2670.00
2810.00

29.90
37.90
46.80
56.60
67.30
79.00
91.60
120.00
152.00
187.00
226.00
269.00
316.00
367.00
421.00
479.00
541.00
606.00
675.00
748.00
825.00
905.00
989.00
1080.00
1170.00
1260.00
1360.00
1470.00
1570.00
1680.00
1800.00
1920.00
2040.00
2160.00
2290.00
2420.00
2560.00
2700.00
2840.00
2990.00

31.70
40.10
49.60
60.00
71.40
83.80
97.10
127.00
161.00
198.00
240.00
285.00
335.00
389.00
446.00
507.00
573.00
642.00
716.00
793.00
874.00
959.00
1050.00
1140.00
1240.00
1340.00
1450.00
1550.00
1670.00
1780.00
1910.00
2030.00
2160.00
2290.00
2430.00
2570.00
2710.00
2860.00
3020.00
3170.00

33.50
42.40
52.40
63.40
75.40
88.50
103.00
134.00
170.00
209.00
253.00
302.00
354.00
411.00
471.00
536.00
605.00
679.00
756.00
838.00
924.00
1010.00
1110.00
1210.00
1370.00
1420.00
1530.00
1640.00
1760.00
1880.00
2010.00
2140.00
2280.00
2420.00
2570.00
2710.00
2870.00
3020.00
3190.00
3350.00
